Semi Automatic Jerrycan Filler 10– 25L for Ink, Detergent, and Glue
Guangzhi’s semi-auto jerrycan filler achieves ±0.3% accuracy for inks/detergents. ATEX/FDA-compliant. Reduces spills to 0.2% & labor by 80%. Free trial!
- Brand： glzon
- Model： GZM_30L
Semi-Automatic Jerrycan Filler GZ-SJF500 Series
*High-Precision Transfer for Ink, Detergent & Glue (10–25L Containers)*
Shanghai Guangzhi Automation’s GZ-SJF500 delivers ±0.3% weight accuracy for filling viscous, foaming, or corrosive liquids into jerrycans (10–25L). Engineered for ink manufacturers, detergent producers, and adhesive suppliers, this ATEX/FDA-compliant system combines operator-guided loading with automated gravimetric control—slashing spillage by 99%, reducing labor by 80%, and ensuring batch-to-batch consistency.
Core Engineering Innovations
Adaptive Gravimetric Filling
Load Cell Precision (0.05% FS): Real-time weight compensation for viscosity shifts in glue/ink (±0.3% accuracy).
FoamSuppress? Technology: Pulsed filling + anti-foam nozzles prevent bubble overflow in detergents.
Operator-Safe Workflow
Ergonomic Rotary Turntable: Operator positions jerrycans while machine fills 10–15 cans/hour.
Foot Pedal Control: Hands-free activation; emergency stop within 0.3s response time.
Corrosion-Resistant Build
316L SS/PTFE Fluid Path: Resists ink pigments, solvent-based glues, and alkaline detergents (pH 1–14).
ATEX Option: Explosion-proof electronics for flammable solvents (e.g., ethanol-based inks).
Zero-Contamination Design
Quick-Change Nozzles: Tool-free swap between jerrycan necks (?45–80mm) in <60 seconds.
Drip-Free Disconnect: Patented shutoff valve eliminates post-fill drips (waste <0.2%).
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | GZ-SJF500-Pro |
| Capacity | 10–25 L (extendable to 30L) |
| Accuracy | ±0.3% |
| Speed | 10–15 cans/hour (operator-dependent) |
| Material Compatibility | Inks, detergents, PVA glues, solvents (≤100,000 cP) |
| Max. Pressure | 15 bar (for high-viscosity silicones) |
| Power | 220V/380V, 50/60Hz, 2.2 kW |
| Air Supply | 0.6 MPa, 0.15 m3/min |
| Filling Nozzle | ATEX-compliant anti-static design |
| Footprint (L×W×H) | 1600 × 900 × 1850 mm |
| Weight | 320 kg |
Performance vs. Manual Filling
| Metric | GZ-SJF500 Semi-Auto | Manual Filling |
|---|---|---|
| Daily Output | 120 jerrycans (8h) | 30 jerrycans |
| Labor Efficiency | 1 operator | 2 operators |
| Spillage Loss | <0.2% | 3–8% |
| Batch Consistency | ±0.3% deviation | ±5–12% deviation |
| ROI Period | 6–9 months | N/A |
Industry-Specific Solutions
Inks & Pigments: Nitrogen purging prevents oxidation; conductive hoses dissipate static.
Detergents: Foam-control algorithm + food-grade seals (FDA 21 CFR).
Industrial Adhesives: Heated hopper option (30–80°C) for epoxy/silicone fills.
