MultiFill MF-3000 SeriesPalletized Multi-Head 30L Paint Drum Filling SystemHigh-Speed Precision Filling • 45 Drums/Hr • ±0.15% Accuracy • ATEX Zone 22 • Color Contamination ControlCore Technical Speci
Palletized Multi-Head 30L Paint Drum Filling System
High-Speed Precision Filling ? 45 Drums/Hr ? ±0.15% Accuracy ? ATEX Zone 22 ? Color Contamination Control
| Parameter | MF-3100 (Standard) | MF-3200X (ATEX) | MF-3300F (Food-Grade) |
|---|---|---|---|
| Capacity | 30L (±0.15%) | 30L (±0.2%) | 30L (±0.1%) |
| Throughput | 45 Drums/Hr | 40 Drums/Hr | 38 Drums/Hr |
| Filling Heads | 7 Independent Servo Heads | Same + ATEX Brushless | 5 Heads (Sanitary Design) |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Viscosity Range | 50-500,000 cP | 100-300,000 cP | 10-1,000,000 cP |
| Pallet Handling | AGV-Compatible Pallet Conveyor<br>? 1,000kg Capacity<br>? LiDAR Positioning ±1mm<br>? Auto-Pallet Change | Same + Ex ia AGV | Hygienic Roller Bed |
| Filling Technology | Gear Pump + Coriolis Meter<br>Per Head: 120L/min Flow<br>±0.1% Head-to-Head Consistency | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Color Change System | ZeroCross? Technology:<br>1. CIP Circuit per Head<br>2. Air-Knife Purge<br>3. <0.1ppm Carryover | Same | Ultra-Sonic Cleaning |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| VOC Control | TripleShield?:<br>1. -0.6bar Vacuum Hood<br>2. Activated Carbon Bed<br>3. Nitrogen Blanketing | Explosion-Proof Vent | VHP Sterilization |
| Changeover Time | <5min (Auto-CIP) | <7min | <4min |
| Power | 480V/60Hz, 18kW | 24VDC Ex ia | 480V/60Hz, 15kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 175.300 |
Performance Metrics:
| Parameter | MF-3000 Performance | Industry Standard |
|---|---|---|
| Head Sync Error | <0.5ms | 5-10ms |
| Color Change | <90s (0.1ppm Carryover) | 15-30min |
| Pallet Cycle Time | 60s (4 Drums/Pallet) | 120-180s |
| Component | Technology | Performance |
|---|---|---|
| Nozzle Design | Laser-Cut Coanda Edge | 0 Droplet Formation |
| Retract Mechanism | Vacuum Suction (-0.6bar) | <0.1ml Residual |
| Surface Treatment | PTFE Nano-Coating (Contact Angle>150°) | 0% Adhesion |
AGV-Integrated Workflow:
Key Metrics:
Pallet Capacity: 4 Drums/Pallet
AGV Speed: 1.5m/s ±0.1m/s
Positioning Accuracy: ±1mm
High-Efficiency Design
? Multi-Head Synchronization: | **Feature**| **Performance**| |-------------------------|------------------------| | Servo Response Time | 0.1ms| | Flow Variance | <0.1% Head-to-Head| | Density Compensation | Real-Time PID Control | ? Zero-Contamination Color Change: 1. Dedicated CIP Circuits per Head 2. 40bar Air-Knife Purge 3. <0.1ppm Cross-Contamination ? Industrial Durability: - Tungsten Carbide Gear Pumps (50,000h MTBF) - IP66 Washdown Protection - 100,000-Hour System MTBF
? ATEX 2014/34/EU Zone 22 ? FDA 21 CFR 175.300 ? ISO 9001:2015
PPG Industrial Coatings Facility:
"After implementing MF-3200X:
Output: 22 → 45 Drums/Hr (+105%)
Color Change Time: 28min → 4.5min
VOC Emissions: ↓97% (Carbon Adsorption)
ROI Period: 6 months"
APPLICABLE BARREL TYPE
