PrecisionFill PF-3000 SeriesAutomatic Inline 30L Paint & Solvent Gravimetric Filling SystemIndustry 4.0 Integrated • 40 Pails/Hr • ±0.1% Accuracy • ATEX Zone 1 • Zero-VOC EmissionCore Technical Sp
Automatic Inline 30L Paint & Solvent Gravimetric Filling System
Industry 4.0 Integrated ? 40 Pails/Hr ? ±0.1% Accuracy ? ATEX Zone 1 ? Zero-VOC Emission
| Parameter | PF-3100 (Standard) | PF-3200X (ATEX) | PF-3300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 30L (±0.1%) | 30L (±0.15%) | 30L (±0.08%) |
| Throughput | 40 Pails/Hr | 36 Pails/Hr | 35 Pails/Hr |
| Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.08% |
| Viscosity Range | 1-500,000 cP | 5-300,000 cP | 10-1,000,000 cP |
| Filling Technology | Coriolis Mass Flow + Servo Gear Pump | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | Glass-Lined Path |
| VOC Containment | TripleLock? System:<br>1. -0.8bar Vacuum Hood<br>2. Activated Carbon Adsorption<br>3. Kalrez?6375 Seals | + Nitrogen Inerting | VHP Sterilization |
| Inline Integration | OPC UA / MQTT Protocol<br>? ERP/MES Connectivity<br>? Auto-Batch Tracking<br>? <100ms Response | PROFINET/Modbus | 21 CFR Part 11 Data Integrity |
| Container Handling | Auto-Guided Vehicles (AGV)<br>Positioning: ±0.5mm LiDAR<br>Payload: 50kg<br>Speed: 1.5m/s | Same + Explosion-Proof AGV | Cleanroom AGV |
| Changeover Time | <45s (Auto-Tooling) | <60s | <40s |
| Power | 480V/60Hz, 6.8kW | 24VDC Ex ia | 480V/60Hz, 6.2kW |
| Certifications | CE, ISO 9001 | ATEX Zone 1 | FDA 21 CFR 175.300 |
Performance Validation:
| Material | Density | Accuracy | Residual |
|---|---|---|---|
| Acetone | 0.79g/ml | ±0.07% | <0.05L |
| Xylene | 0.86g/ml | ±0.09% | <0.06L |
| UV-Cured Paint | 1.2g/ml | ±0.12% | <0.08L |
| Layer | Technology | Performance |
|---|---|---|
| Primary Barrier | -0.8bar Vacuum Hood | 99.9% Splash Containment |
| Secondary Filter | Activated Carbon Bed (5kg) | 99.97% VOC Adsorption |
| Tertiary Seal | Helium-Leak Verified Seals | <10?? mbar·L/s Leak Rate |
Smart Factory Connectivity
IIoT Features:
Predictive Maintenance:
| Component | Monitoring Parameter | Alert Threshold |
|---|---|---|
| Pump Wear | Vibration Analysis | >4.5mm/s RMS |
| Seal Degradation | Friction Torque | >8N·m |
Quality Sentinel:
| Defect | AI Action |
|---|---|
| Color Variance ΔE>0.5 | Formula Adjustment |
| Density Shift >1% | Flow Rate Recalibration |
| Subsystem | PF-3100 (Standard) | PF-3200X (ATEX) |
|---|---|---|
| Flow Meter | Coriolis (0.05% Accuracy) | ATEX Certified Coriolis |
| AGV System | LiDAR SLAM Navigation | Ex ia Rated AGV |
| Filtration | HEPA H13 + Carbon Bed | Explosion-Proof Filter |
| Control System | Siemens S7-1500 PLC + IoT Edge | Same + SIL-3 Certification |
Material Science:
Corrosion Resistance:
| Material | Chemical Compatibility | Certification |
|---|---|---|
| Hastelloy C276 | HCl ? Chlorides ? Solvents | NACE MR0175 |
| 316L EP | Alkalis ? Organic Acids | FDA 21 CFR 175.300 |
| Zirconium | HNO? ? H?SO? Concentrated | ASME BPV Code |
1. AGV Pail Delivery → 2. Robotic Lid Removal → 3. Nitrogen Purging (O?<0.3%) → 4. Gravimetric Filling (±0.1%) → 5. Vapor Recovery → 6. Torque-Sealing (30-100 N·m) → 7. Weight Verification → 8. AGV Palletizing
Cycle Time: 90 seconds/pail
? ATEX 2014/34/EU Zone 1 ? FDA 21 CFR 175.300 ? ISO 9001:2015 ? IECEx IEC 60079
Sherwin-Williams Automotive Plant:
"After PF-3200X implementation:
Output: 22 → 40 Pails/Hr (+82%)
VOC Emissions: ↓99% (Carbon Adsorption)
Accuracy: ±0.5% → ±0.08%
ROI Period: 7 months"
