GZM CSC-5000 counts and seals tablets, capsules, or small parts at 300 packs/minute with 99.99% accuracy. Features AI vision, hermetic sealing, and CFR 21 compliance. Reduces counting errors to 1:100,000 and seal failures to <0.1%. Ideal for pharma blister packs and FMCG sachets. Includes leak testing and tamper-evidence.
Precision Counting & Hermetic Sealing for Tablets, Capsules, and Small Parts
The GZM CSC-5000 integrates high-speed optical counting (±99.99% accuracy) and tamper-proof sealing into one compact system. Designed for blister packs, vials, and pouches, it processes 120-300 units/minute with ISO 15378 compliance, eliminating counting errors and ensuring 100% seal integrity for sensitive products.
| Parameter | Specification |
|---|---|
| Counting Range | Tablets: 0.5–25mm; Capsules: #5–000 |
| Counting Accuracy | ±99.99% (pharma-grade) / ±99.95% (general) |
| Sealing Types | Blister (aluminum/ALU-ALU), pouches (heat/cold seal), vials (induction) |
| Throughput | 120–300 packs/minute |
| Seal Strength | 1.5–8 N/15mm (adjustable) |
| Power | 220V/60Hz, 3.8 kW |
| Material Compatibility | PVC/PVDC, PET/ALU, laminated films |
| Footprint | 1.8 × 1.2 m |
| Component | Innovation | Benefit |
|---|---|---|
| Optical Counter | AI-vision + multi-spectral sensors | Detects chips/cracks (≥0.1mm defects) |
| Sealing System | PID-controlled heat + pressure profiling | Prevents under/over-sealing (≤0.5% failure) |
| Reject Mechanism | Pneumatic diverter + data logging | Isolates defects with 99.98% reliability |
| HMI | 10" touchscreen with CFR 21 Part 11 compliance | Audit-ready batch reports |
| Metric | CSC-5000 | Manual Operation | Improvement |
|---|---|---|---|
| Speed | 300 packs/min | 20 packs/min | 15× faster |
| Counting Errors | 1 in 100,000 | 1 in 500 | 99.8% reduction |
| Seal Failure | <0.1% | 2–5% | 98% reduction |
| Labor | 1 operator | 5 workers | 80% cost saving |
Pharma: Tablets, capsules, lozenges (GMP/WHO compliance)
Electronics: SMD components, microchips, connectors
FMCG: Coffee pods, condiment sachets, tea bags
Hardware: Screws, bolts, washers (bulk-to-pack)
Cross-Contamination Prevention:
Quick-change sealing heads (3-min swap)
Self-sanitizing UV chamber option
Material Savings:
Film usage optimization (AI nesting algorithms)
Reject recovery system for recyclables
Regulatory Ready:
Validatable per ASTM F1140/F2054
Data encryption for serialization (GS1 standards)
? Zero Recalls: 100% leak detection (sensitivity: 5μm defects)
? Flexible Formatting: Handles strips, blisters, pouches (10–200mm)
? Energy Efficient: 30% lower power vs. modular systems
? Plug-and-Play: 4-hour installation with auto-calibration
Nitrogen Flushing: O? < 0.5% for oxidation-sensitive products
Vision Inspection: OCR for batch codes, Braille verification
Robotic Case Packing: Integrated Delta robot
Ex-Proof Kit: ATEX Zone 22 for solvent-based printing
