GZM DPB-3500 automates cement/mortar packaging at 1,200 bags/hour with ±0.5% accuracy. Features tungsten carbide augers, ISO Class 0 dust control, and robotic palletizing. Reduces waste to 0.2% and labor by 85%. Handles 20-50kg woven/paper bags. ATEX-compliant for explosive dust zones. Ideal for dry mix plants and cement terminals.
High-Speed Dust-Free Packaging for Abrasive Building Powders
The GZM DPB-3500 automates the filling, weighing, and sealing of dry construction materials into 25-50kg bags at 1,200 bags/hour with ±0.5% accuracy. Engineered for cement plants and dry mix facilities, it features hardened-wear components, ISO 8573-1 Class 0 dust control, and robotic palletizing integration to slash labor costs by 85%.
| Parameter | Specification |
|---|---|
| Bag Types | Woven PP/paper/valve sacks (L: 60-100cm) |
| Capacity | 20-50kg (adjustable in 100g increments) |
| Accuracy | ±0.5% (loss-in-weight system) |
| Throughput | 900-1,200 bags/hour (25kg standard) |
| Dust Emission | <1 mg/m3 (HEPA H13 filtration) |
| Power | 380V/50Hz, 22 kW |
| Material Handling | Cement, mortar, plaster, silica sand |
| Palletizing | Integrated robot (1,200 kg/hour capacity) |
| Challenge | DPB-3500 Solution |
|---|---|
| Abrasive Wear | Tungsten carbide-coated auger (10× lifespan) |
| Material Bridging | Fluidizing hopper + pneumatic hammer |
| Dust Explosion Risk | ATEX Zone 22 + spark detection |
| Bag Sealing Failure | Double-stitch sewing + glue sealing |
| Metric | DPB-3500 | Manual Line | Savings |
|---|---|---|---|
| Daily Output | 28,800 bags | 3,600 bags | 8× higher |
| Material Waste | 0.2% | 3.5% | 94% reduction |
| Labor | 1 supervisor | 12 workers | 85% cost cut |
| Bag Damage | <0.1% | 2.8% | 96% reduction |
Cement: Portland, slag, masonry
Dry Mixes: Tile adhesive, grout, self-leveling compounds
Gypsum: Plaster, stucco, joint compounds
Aggregates: Silica sand, vermiculite, perlite
Abrasion-Resistant Filler: Carbide-tipped auger (HRC 65)
Anti-Static System: Ionized air curtain + grounded belts
Dust Hood: Negative pressure design (ISO 14644-1 Class 7)
Sewing Head: Double-thread servo stitcher
HMI Control: 12" touchscreen with OEE dashboard
? Zero Downtime: Quick-change wear parts (15-min swap)
? Smart Calibration: Auto-adjusts for density changes (±15%)
? Compliance Ready: CE, OIML R61, ISO 9001
? Moisture Defense: Dehumidified air purge (<1% RH)
Explosion-Proof Kit: ATEX II 1D (Zone 21/22)
Bulk Bag (FIBC) Station: 500-2,000kg capacity
Automated Stretch Wrapper: Pallet wrapping integration
RFID Tracking: Bag-level traceability
