Bag Kicker Conveyor
Shanghai Guangzhi’s Bag Kicker Conveyor diverts 10-50kg sacks at 40 bags/min. Precision servo ejection, zero-impact handling & ATEX option. CE/FDA compliant for harsh plants.
- Brand： glzon
- Model： GZM
Product Essence: Precision High-Speed Diversion
Shanghai Guangzhi Automation’s Bag Kicker Conveyor revolutionizes packaging line efficiency – instantly diverting 10-50kg sacks (PP woven, paper, jute) at 40 bags/minute with servo-powered precision. Engineered for cement, fertilizer, and chemical plants, this system combines zero-impact ejection, AI-driven trajectory control, and ATEX-compliant construction to eliminate manual sorting errors while withstanding 24/7 abrasive environments.
Core Technology Innovations
1. Intelligent Bag Handling
Adaptive Force Control: Servo-actuated kicker arms adjust force (50-500N) based on bag weight/size
LiDAR Positioning: 3D scanning ensures ±2mm ejection accuracy
Collision Avoidance: AI predicts bag trajectories to prevent mid-air collisions
2. Heavy-Duty Industrial Design
Hardox 450 Impact Plates: 10M+ cycle lifespan in cement/ore environments
Dust-Immune Actuators: IP68-rated servo cylinders (ATEX Zone 22 option)
Modular Frame: Bolt-on extensions for multi-lane sorting (up to 5 lanes)
3. Zero-Damage Guarantee
Cushioned Ejection: Polyurethane dampeners absorb 95% impact energy
Anti-Snag Geometry: Radiused edges prevent bag tearing
Speed-Matching: Syncs with conveyor (0.5-2.5 m/s) for smooth transfers
Technical Specifications
| Parameter | Standard Model | ATEX Model |
|---|---|---|
| Bag Weight | 10-50kg | 10-40kg |
| Throughput | 40 bags/min | 35 bags/min |
| Divert Angle | 30°-90° (±1°) | 30°-75° |
| Actuation Time | 0.3 sec | 0.4 sec |
| Conveyor Width | 600-1000mm | 600-800mm |
| Power | 380V/50Hz, 3.2kW | 24VDC intrinsic safety |
| Noise Level | ≤70 dB(A) | ≤68 dB(A) |
| Footprint (L×W) | 1500×800mm | 1600×800mm |
Industry-Specific Solutions
Cement & Minerals
Tungsten-carbide wear strips for abrasive dust
Vibration-dampening mounts
Fertilizer Plants
Corrosion-resistant 316SS kicker plates
Humidity-controlled enclosures
Food & Pharma
FDA-grade UHMWPE contact surfaces
CIP washdown-ready (IP69K)
Chemical Sector
ATEX Zone 21 explosion-proof actuators
Static-dissipative belts (<10? Ω)
Smart Control Ecosystem
PLC Integration: Profinet/Ethernet IP connectivity
10" HMI Dashboard:
Real-time diversion logs
Force calibration profiles
Predictive maintenance alerts
Safety Systems:
Laser scanner emergency stops
Jam detection auto-reverse
Operational Impact
Indonesian Fertilizer Plant Case:
Challenge: Manual sorting caused 8% misroutes + bag damage
Solution: Dual-lane kicker system with AI trajectory control
Results:
? 99.9% sort accuracy
? Zero bag damage
? ROI in 5 months
Global Compliance & Value
Certifications:
CE Machinery Directive 2006/42/EC
ATEX 2014/34/EU (Zone 22)
ISO 9001:2015
Cost Efficiency:
30% Energy Recovery: Regenerative drives
Modular Upgrades:
Vision-based defect rejection
RFID sorting gates
Automatic lane balancing
Support Network:
24/7 remote diagnostics via IIoT
Critical Spares Dispatch: ≤48h global delivery
Servo actuator modules
Hardox impact plates
Dust-proof sensors
AR Maintenance: Guided repairs via HoloLens
