ViscFill VF-5000 SeriesSemi-Automatic Precision Filling System for Varnishes & AdhesivesIndustrial-Grade Gravimetric Control • 40 Drums/Hr • ±0.1% Accuracy • ATEX/FDA Dual Compliance • Zero-Drip T
Semi-Automatic Precision Filling System for Varnishes & Adhesives
Industrial-Grade Gravimetric Control ? 40 Drums/Hr ? ±0.1% Accuracy ? ATEX/FDA Dual Compliance ? Zero-Drip Technology
| Parameter | VF-5100 (Standard) | VF-5200X (ATEX) | VF-5300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 5-30L (±0.1%) | 5-30L (±0.15%) | 5-30L (±0.08%) |
| Throughput | 40 Drums/Hr | 36 Drums/Hr | 35 Drums/Hr |
| Viscosity Range | 100-500,000 cP | 500-300,000 cP | 50-1,000,000 cP |
| Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.08% |
| Filling Technology | Servo Piston + Coriolis Meter | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Drip Control | Vacuum Suction (-0.8bar)<br>+ Coanda Adhesion Nozzle | Spring-Loaded Nozzle | Ultrasonic Scraper |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Heating System | Jacketed Path (40-80°C±1°C) | Same | Viscosity-Adaptive Control |
| Agitation | Pulsed Helical Agitator<br>0.1-10 RPM Variable | ATEX Brushless Motor | Low-Shear Paddle |
| Container Types | Buckets ? Drums ? Jerrycans<br>Lid: Screw ? Press ? Snap | UN-Certified Containers | Aseptic Liners |
| Changeover Time | <90s (Tool-Free) | <110s | <75s |
| Power | 380V/50Hz, 5.8kW | 24VDC Ex ia | 380V/50Hz, 5.2kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 175.300 |
Performance Validation:
| Material | Viscosity | Drip Volume | Industry Standard |
|---|---|---|---|
| Epoxy Resin | 120,000 cP | 0mg | 15-30mg |
| Polyurethane | 80,000 cP | 0mg | 10-25mg |
| Acrylic Varnish | 20,000 cP | 0mg | 8-20mg |
| Component | Technology | Precision |
|---|---|---|
| Real-Time Rheometer | In-line Viscometer | ±1% Brookfield |
| Temp Control | PID with Kalman Filter | ±0.5°C |
| Density Compensation | Coriolis Mass Flow Meter | ±0.05% Reading |
Wood Coatings & Adhesives
| Challenge | Innovation | Performance |
|---|---|---|
| Skin Formation | Nitrogen Blanketing (O?<0.3%) | 0% Surface Skinning |
| Settling | Pulsed Ultrasonic Agitation | 99.8% Homogeneity |
| Bubble Entrapment | Vacuum Degassing (-0.9bar) | 0% Air Inclusion |
Industrial Bonding Agents
Static Control:
Curing Prevention:
| Technology | Effect |
|---|---|
| Cooled Nozzle (5-15°C) | Delayed Polymerization |
| UV-Blocking Enclosure | Prevents Premature Cure |
Medical Adhesives
| cGMP Feature | Technical Solution |
|---|---|
| Cleanability | SIP Validation (121°C/30min) |
| Data Integrity | 21 CFR Part 11 Audit Trail |
| Material Traceability | RFID/NFC Tracking |
1. Manual Container Placement → 2. Auto-Nozzle Alignment (±0.5mm) → 3. Viscosity-Temp Calibration → 4. Precision Filling (±0.1%) → 5. Vacuum Nozzle Retract → 6. Torque-Controlled Sealing → 7. Weight Verification → 8. Palletizing
Cycle Time: 90 seconds/drum
Precision Engineering
? Gravimetric Mastery: | **Technology**| **Performance**| |-------------------------|------------------------| | Coriolis Meter| ±0.05% Density Accuracy | | Load Cells| Air Buoyancy Compensation | | Adaptive PID| ±0.1% Fill Consistency | ? Zero-Waste Architecture: 1. Vacuum Suction (-0.8bar) 2. Laser-Cut Capillary Break 3. PTFE Nano-Coating ? Industrial Reliability: - Tungsten Carbide Components (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 22 ? FDA 21 CFR 175.300 ? ISO 9001:2015
Henkel Adhesive Production Line:
"After implementing VF-5200X:
Output: 22 → 40 Drums/Hr (+82%)
Material Savings: 2.8% → 0.12%
Drip Waste: 1.5L/day → 0.02L/day
ROI Period: 5.5 months"
