DualFill DF-8000 Series20L Auto Ash Capping & Ink Filling SystemIndustrial-Grade Dual-Function Platform • 45 Drums/Hr • ±0.15% Accuracy • ATEX Zone 22 • Zero Cross-ContaminationCore Technical Spec
20L Auto Ash Capping & Ink Filling System
Industrial-Grade Dual-Function Platform ? 45 Drums/Hr ? ±0.15% Accuracy ? ATEX Zone 22 ? Zero Cross-Contamination
| Parameter | DF-8100 (Standard) | DF-8200X (ATEX) | DF-8300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 20L (±0.15%) | 20L (±0.2%) | 20L (±0.1%) |
| Throughput | 45 Drums/Hr | 40 Drums/Hr | 38 Drums/Hr |
| Dual-Function Mode | Ash Capping + Ink Filling | Same | Same + Sterile Mode |
| Ash Capping Accuracy | ±0.5% Torque Control | ±0.6% | ±0.4% |
| Ink Filling Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.08% |
| Material Compatibility | Fly Ash ? Carbon Black ? Pigment Inks ? Solvent Inks | Explosive Dusts | USP-Grade Materials |
| Ash Capping Tech | Vacuum-Assisted Dust Hood<br>HEPA H14 Filtration<br>Inflatable Silicone Seal | + Nitrogen Inerting | VHP Sterilization |
| Ink Filling Tech | Coanda Adhesion Nozzle<br>Coriolis Mass Flow Meter<br>Real-Time Viscosity Control | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Changeover Time | <120s (Tool-Free) | <150s | <90s |
| Power | 380V/50Hz, 8.5kW | 24VDC Ex ia | 380V/50Hz, 7.2kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 175.300 |
Performance Validation:
| Material | Dust Emission | OSHA Limit | DF-8000 Performance |
|---|---|---|---|
| Fly Ash | 0.8mg/m3 | 15mg/m3 | ↓95% |
| Carbon Black | 0.5mg/m3 | 3.5mg/m3 | ↓86% |
| Component | Technology | Ink Performance |
|---|---|---|
| Viscometer | Real-Time Rheometer | ±1% Brookfield Accuracy |
| Nozzle Design | Laser-Cut Capillary Break | 0% Splatter |
| Color Control | In-line Spectrophotometer | ΔE<0.5 (CIELab) |
Cycle Time: 80 seconds/drum
Industry-Leading Innovation
? Cross-Contamination Prevention: | **Feature**| **Specification**| |------------------------|--------------------------| | Isolated Zones | Positive Air Pressure Differential | | Color-Coded Tools| Quick-Change Cartridges | | UV-C Decon Tunnel| 6-log Pathogen Reduction | ? Precision Engineering: 1. Ash Capping: ±0.5% Torque Accuracy (5-100 N·m) 2. Ink Filling: ±0.15% Gravimetric Accuracy 3. 99.95% Defect-Free Seals ? Industrial Durability: - Tungsten Carbide Auger (50,000-Hour Lifespan) - IP66 Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 22 ? FDA 21 CFR 175.300 ? EHEDG EL Class I
Sherwin-Williams Industrial Coatings:
"After implementing DF-8200X:
Output: 25 → 45 Drums/Hr (+80%)
Dust Emissions: ↓98% (Carbon Black Line)
Ink Color Variance: ΔE>1.0 → ΔE<0.3
ROI Period: 5.8 months"
APPLICABLE BARREL TYPE
