VegOilFill VF-3000 SeriesPrecision 30L Jerry Can Filling System for Vegetable OilsFood-Grade Gravimetric Packaging • 45 Cans/Hr • ±0.1% Accuracy • EHEDG/FDA Certified • Nitrogen PreservationCore Techn
Precision 30L Jerry Can Filling System for Vegetable Oils
Food-Grade Gravimetric Packaging ? 45 Cans/Hr ? ±0.1% Accuracy ? EHEDG/FDA Certified ? Nitrogen Preservation
| Parameter | VF-3100 (Standard) | VF-3200P (Pharma-Grade) | VF-3300H (High-Viscosity) |
|---|---|---|---|
| Capacity | 30L (±0.1%) | 30L (±0.08%) | 30L (±0.15%) |
| Throughput | 45 Cans/Hour | 40 Cans/Hour | 35 Cans/Hour |
| Accuracy | ±0.1% Gravimetric | ±0.08% | ±0.15% |
| Viscosity Range | 50-50,000 cP | 50-30,000 cP | 500-500,000 cP |
| Filling Technology | Coriolis Mass Flow Meter<br>? Real-Time Density Compensation<br>? 100L/min Flow Rate | Peristaltic Pump (FDA) | Heated Gear Pump |
| Material Contact | 316L EP (Ra<0.4μm) | 316L EP (Ra<0.2μm) | Ceramic-Coated Path |
| Oxygen Control | Nitrogen Blanketing<br>O?<0.1% Headspace | Same + Argon Flushing | Vacuum Degassing (-0.8bar) |
| Drip Prevention | Coanda Adhesion Nozzle<br>? Laser-Cut Capillary<br>? PTFE Nano-Coating | Ultrasonic Vibration | Vacuum Suction (-0.6bar) |
| Container Handling | UN-Certified Jerry Cans<br>Materials: HDPE/Stainless Steel<br>Lid: Gasket-Sealed Screw Cap | Same + Aseptic Liners | Heavy-Duty Metal Cans |
| Cleaning System | CIP 15-min Cycle<br>ATP<3 RLU Validation | SIP/CIP 12-min Cycle | Solvent Purge System |
| Changeover Time | <60s (Tool-Free) | <50s | <75s |
| Power | 380V/50Hz, 4.5kW | 380V/50Hz, 4.2kW | 380V/50Hz, 5.8kW |
| Certifications | EHEDG EL Class I ? FDA 21 CFR 177.2600 | 3-A Sanitary Standard | ISO 22000 |
Quality Validation:
| Oil Type | Peroxide Value (Pre/Post) | Shelf Life Extension |
|---|---|---|
| Sunflower Oil | 1.2 → 0.8 meq/kg | +180 Days |
| Olive Oil | 4.0 → 1.5 meq/kg | +240 Days |
| Palm Oil | 3.5 → 1.2 meq/kg | +210 Days |
| Component | Technology | Performance |
|---|---|---|
| Load Cells | Air Buoyancy Compensation | ±0.05% FS Accuracy |
| Temp Sensor | PT1000 ±0.1°C | Density Correction ±0.08% |
| Flow Control | Adaptive PID Algorithm | ±0.1% Fill Consistency |
Hygienic Design Certification
Cleanability Metrics:
| Parameter | VF-3200P Performance | Industry Standard |
|---|---|---|
| CIP Time | 12 Minutes | 30 Minutes |
| ATP Test | <2 RLU | <10 RLU |
| Microbial Risk | 0 CFU/100cm2 | <10 CFU/100cm2 |
1. Manual Can Loading → 2. Auto-Lid Removal → 3. Nitrogen Purging (O?<0.1%) → 4. Submerged Filling (±0.1%) → 5. Coanda Nozzle Retract → 6. Torque-Controlled Sealing (20-50 N·m) → 7. Weight Verification → 8. Laser Date Coding → 9. Palletizing
Cycle Time: 80 seconds/can
Precision & Preservation
? Oxidation Control: | **Technology**| **Performance**| |-------------------------|------------------------| | Nitrogen Blanketing| O?<0.1% Headspace| | UV-C Sterilization | 6-log Pathogen Reduction | | Headspace Flushing| 99.95% Oxygen Removal | ? Zero-Contamination: 1. EHEDG-Certified Surfaces 2. CIP/SIP Validated (ATP<3 RLU) 3. Isolated Filling Zone (ISO Class 5) ? Production Efficiency: - 45 Cans/Hour Sustained Output - <60s Tool-Free Changeover - 99.3% Uptime Reliability
? EHEDG EL Class I (Certificate #EH-2024-887) ? FDA 21 CFR 177.2600 ? 3-A Symbol 09-03 ? ISO 22000:2018
Wilmar International Edible Oil Plant:
"After implementing VF-3100:
Output: 25 → 45 Cans/Hour (+80%)
Peroxide Value: ↓40% (Extended Shelf Life)
Spill Loss: 0.8L/shift → 0.02L/shift
ROI Period: 5.2 months"
