ChemiFill Pro CP-5000 SeriesIntegrated Chemical Bottle & Pail Filling-Capping SystemPrecision Liquid Handling • 120 Containers/Hr • ±0.15% Accuracy • ATEX/FDA Dual Compliance • Zero-Spill Technolo
Integrated Chemical Bottle & Pail Filling-Capping System
Precision Liquid Handling ? 120 Containers/Hr ? ±0.15% Accuracy ? ATEX/FDA Dual Compliance ? Zero-Spill Technology
| Parameter | CP-5100 (Standard) | CP-5200X (ATEX) | CP-5300P (Pharma-Grade) |
|---|---|---|---|
| Container Compatibility | Bottles (0.5-20L) ? Pails (5-30L) ? Jerrycans | Same + Safety Cans | Same + USP Containers |
| Throughput | 120 Units/Hour | 100 Units/Hour | 90 Units/Hour |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Viscosity Range | 1-500,000 cP | 10-300,000 cP | 50-1,000,000 cP |
| Filling Technology | Twin-Coriolis Mass Flow Meters | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Capping Technology | Servo Torque Control (5-100 N·m) | Magnetic Clutch System | Stepper Motor Precision |
| Cap Compatibility | Screw ? Snap ? Press-Twist ? Child-Resistant | Same + Vapor-Lock Caps | Tamper-Evident Seals |
| Material Contact | 316L SS (Ra<0.8μm) | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Containment System | Triple Barrier:<br>1. -30Pa Vacuum Hood<br>2. Ionized Air Curtain<br>3. Drip Tray Recovery | + Nitrogen Inerting | + VHP Sterilization |
| Changeover Time | <90s (Tool-Free) | <120s | <75s |
| Power | 380V/50Hz, 8.5kW | 24VDC Ex ia | 380V/50Hz, 7.2kW |
| Certifications | CE, ISO 9001 | ATEX Zone 2 | FDA 21 CFR 210/211 |
Performance Validation:
| Chemical | Viscosity | Spill Volume | Industry Standard |
|---|---|---|---|
| Acetone | 300 cP | 0.2ml | 5-8ml |
| Silicone Oil | 50,000 cP | 0.4ml | 10-15ml |
| Corrosive Acid | 150 cP | 0.3ml | 8-12ml |
| Component | Innovation | Precision |
|---|---|---|
| Torque Sensor | Nanoscale Strain Gauge | ±0.5% Reading |
| Thread Detection | Laser-Guided Alignment | ±0.3° Angular Error |
| Defect Rejection | AI Vision (0.2mm Accuracy) | 99.99% Detection Rate |
Chemical Solvents
| Feature | ATEX Solution | Performance |
|---|---|---|
| Static Control | Ionized Air Curtain (10? ions/cm3) | <1kV Surface Charge |
| Vapor Containment | Activated Carbon Adsorption | 99.95% VOC Recovery |
| Corrosion Resistance | Zirconium Alloy Flow Path | Resists HCl/HF Acid |
Cosmetics & Pharma
Hygienic Design:
Oxygen Barrier:
| Technology | Effect |
|---|---|
| N? Flushing | O?<0.1% Headspace |
| Vacuum Capping | -0.5bar Residual Pressure |
Industrial Lubricants
| Challenge | Innovation |
|---|---|
| High-Viscosity Flow | Heated Path (80°C±1°C) |
| Adhesion Control | PTFE Nano-Coating |
| Dust Contamination | ISO Class 5 Air Shower |
**10" HMI with ChemiOS?**
AI-Driven Features:
Quality Sentinel:
| Parameter | Action |
|---|---|
| Fill Weight Error >1% | Auto-Reject + Alert |
| Cap Defect Detected | Pneumatic Ejection |
Predictive Maintenance:
| Component | Alert Threshold |
|---|---|
| Pump Wear | Vibration >4.5mm/s |
| Capper Alignment | >0.5° Deviation |
Precision Engineering Mastery
? Zero-Spill Architecture: | **Technology**| **Performance**| |-------------------------|------------------------| | Vacuum Hood| -30Pa ±2Pa| | Coanda Nozzle| 0 Droplet Formation| | Ionized Air Curtain| Static <0.5kV| ? Capping Perfection: 1. ±0.5% Torque Accuracy (5-100 N·m) 2. 0.2mm Thread Defect Detection 3. <3s Cap-Type Changeover ? Industrial Durability: - Tungsten Carbide Contact Points - IP69K Washdown Protection - 100,000-Hour MTBF
? ATEX 2014/34/EU Zone 2 ? FDA 21 CFR 210/211 ? EHEDG EL Class I ? ISO 9001:2015
Dow Chemical Packaging Line:
"After implementing CP-5200X:
Output: 65 → 120 Units/Hour (+85%)
Spill Reduction: 1.8L/shift → 0.15L/shift
Cap Defect Rate: 2.3% → 0.05%
ROI Period: 5.2 months"
