MegaFill MF-12000 SeriesIndustrial Open-Mouth Bagging System for Bulk Solids & Granules80 Bags/Hr • ±0.15% Accuracy • Triple Dust Containment • ATEX Zone 22 Certified • Heavy-Duty ConstructionEngi
Industrial Open-Mouth Bagging System for Bulk Solids & Granules
80 Bags/Hr ? ±0.15% Accuracy ? Triple Dust Containment ? ATEX Zone 22 Certified ? Heavy-Duty Construction
Performance Validation:
| Material | Dust Emission | OSHA Limit | Industry Standard |
|---|---|---|---|
| Wheat Flour | 0.6mg/m3 | 10mg/m3 | 15-25mg/m3 |
| Polymer Pellets | 0.9mg/m3 | 15mg/m3 | 20-35mg/m3 |
| Mineral Sand | 1.2mg/m3 | 5mg/m3 | 8-18mg/m3 |
| Component | Technology | Performance |
|---|---|---|
| Load Cells | Temperature-Compensated (ASTM E74) | ±0.05% Resolution |
| Air Buoyancy | Real-Time Atmospheric Compensation | ±0.1% Accuracy |
| Feed Control | AI-Predictive Flow Algorithm | ±0.15% Fill Consistency |
| Parameter | MF-1210 (Standard) | MF-1220X (ATEX) | MF-1230F (Food Grade) |
|---|---|---|---|
| Bag Capacity | 25-50kg (±0.15%) | 25-50kg (±0.2%) | 25-50kg (±0.1%) |
| Throughput | 80 Bags/Hour | 75 Bags/Hour | 70 Bags/Hour |
| Material Compatibility | Grains ? Polymers ? Minerals ? Chemicals ? Animal Feed | Explosive Dusts | USDA/FDA Compliant Materials |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Filling Technology | Twin Auger System<br>? Tungsten Carbide Tips<br>? 300kg/min Flow Rate | ATEX Gear System | 316L EP Auger |
| Dust Control | TripleShield? System<br>1. Negative Pressure Hood<br>2. Pulse-Jet HEPA Filter<br>3. Collar Seal Inflation | + Nitrogen Inerting | + UV-C Sterilization |
| Material Contact | Hardox 500 ? Alumina Ceramic | Hastelloy C276 | 316L EP (Ra<0.4μm) |
| Wear Resistance | Auger Lifespan: 80,000 Tons | 70,000 Tons | 60,000 Tons |
| Bag Types | Woven PP ? Paper ? FIBC Liners<br>Size: 50×90cm to 60×120cm | Same | Food-Grade Laminates |
| Sealing Methods | Stitching ? Heat Seal ? Adhesive Tape ? Zipper | Same | Ultrasonic Seal |
| Changeover Time | <90s (Tool-Free) | <110s | <100s |
| Power | 480V/60Hz, 25kW | 24VDC Ex ia | 480V/60Hz, 22kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 117 ? EHEDG |
Agriculture & Grains
| Feature | Technology | Performance |
|---|---|---|
| Insect Prevention | UV Light Trap + Air Curtain | 100% Infestation Free |
| Moisture Control | -40°C Dew Point Air Flushing | RH<12% in Path |
| Segregation | Fluidized Bed Agitator | 99.8% Homogeneity |
Chemicals & Minerals
Explosion Safety:
Corrosion Resistance:
| Material | Chemical Compatibility |
|---|---|
| Hastelloy C276 | Acids ? Chlorides ? Solvents |
| PTFE-Lined Path | Caustics ? Oxidizers |
Plastics & Polymers
| Challenge | Solution |
|---|---|
| Electrostatic Cling | Ionized Air Curtain (10? ions/cm3) |
| Particle Fracture | Low-Shear Auger (12 RPM) |
| Dust Explosion | ATEX Zone 22 Compliance |
**15" HMI with BulkOS?**
AI-Driven Features:
Quality Control:
| Parameter | Action |
|---|---|
| Density Shift >1% | Flow Recalibration |
| Particle Size Change | Auger Speed Adjustment |
Zero-Downtime:
| Component | Alert Threshold |
|---|---|
| Auger Wear | Torque >125% Baseline |
| Filter Saturation | ΔP >0.7bar |
1. Auto Bag Placement → 2. Collar Seal Inflation → 3. Precision Filling (±0.15%) → 4. Dust Extraction → 5. Multi-Mode Sealing → 6. Weight Verification → 7. Automated Palletizing
Cycle Time: 45 seconds/bag
Unmatched Performance
? Dust Containment Mastery: | **Technology**| **Efficiency**| |-------------------------|------------------------| | -50Pa Vacuum Hood| 98% Fugitive Dust Capture | | H14 HEPA Filtration | 99.97%@0.3μm (EN 1822) | | Air Curtain | 100% Spill Prevention | ? Extreme Durability: - Tungsten Carbide Auger (80,000-Ton Lifespan) - Hardox 500 Scraper Blades - IP66 Washdown Protection ? High-Speed Precision: - 80 Bags/Hour Sustained Output - ±0.15% Gravimetric Accuracy - <90s Tool-Free Changeover
? ATEX 2014/34/EU Zone 22 ? OSHA 29 CFR 1910.269 ? ISO 9001:2015 ? CE EN 614-1 ? FDA 21 CFR 117 (MF-1230F)
Cargill Grain Processing Facility:
"MF-1210 Implementation Results:
Output: 45 → 80 Bags/Hour (+78%)
Dust Emissions: 22mg/m3 → 0.8mg/m3 (↓96%)
Material Savings: 1.8% → 0.12% ($580,000/year)
Maintenance Intervals: 2x Longer"
