PureFill PF-7000 SeriesFood-Grade Open-Mouth Bag Packing SystemEHEDG Certified • 60 Bags/Hr • ±0.1% Accuracy • Allergen Control • USDA Organic/Kosher/Halal CompliantHygienic Engineering Breakthroughs1
Food-Grade Open-Mouth Bag Packing System
EHEDG Certified ? 60 Bags/Hr ? ±0.1% Accuracy ? Allergen Control ? USDA Organic/Kosher/Halal Compliant
Microbiological Validation:
| Parameter | PF-7000 Performance | FDA Threshold |
|---|---|---|
| Aerobic Count | <1 CFU/100cm2 | ≤10 CFU/cm2 |
| Allergen Residue | <0.5ppm ELISA Test | ≤1ppm |
| Metal Detection | 0.3mm Fe / 0.4mm Non-Fe | HACCP Critical Limit |
| Technology | Function | Preservation Impact |
|---|---|---|
| Low-Shear Auger | 15 RPM Counter-Rotation | 0% Starch Damage |
| Moisture Control | -40°C Dew Point Air Flushing | RH<12% in Path |
| Anti-Static | Ionized Air Curtain (10? ions/cm3) | 0% Powder Adhesion |
| Parameter | PF-7100 (Standard) | PF-7200A (Allergen-Free) | PF-7300O (Organic) |
|---|---|---|---|
| Bag Capacity | 5-25kg (±0.1%) | 5-25kg (±0.08%) | 5-25kg (±0.12%) |
| Throughput | 60 Bags/Hour | 55 Bags/Hour | 50 Bags/Hour |
| Material Compatibility | Flour ? Sugar ? Grains ? Powdered Milk ? Starch | Nut-Free Facility | USDA Organic Certified |
| Accuracy | ±0.1% Gravimetric | ±0.08% | ±0.12% |
| Filling Technology | Servo Auger + Multi-Cell Load System | Same + Dedicated Change Parts | Ceramic Auger |
| Material Contact | 316L EP (Ra<0.4μm) | 316L EP (Ra<0.2μm) | Glass-Lined Path |
| Contamination Control | Triple Barrier:<br>1. H14 HEPA Filtration<br>2. Zoned Air Pressure<br>3. Magnetically Sealed Joints | + Allergen Testing Port | + Ozone Flush |
| Cleanability | CIP/SIP Validated<br>ATP<3 RLU Post-Clean | <2 RLU | Organic Acid Cleaner Ready |
| Sealing Methods | Stitch ? Heat Seal ? Ultrasonic ? Adhesive Tape | Same | Compostable Glue |
| Certifications | EHEDG EL Class I ? FDA 21 CFR 117 | SQF Level 3 | USDA Organic ? Kosher ? Halal |
| Changeover Time | <120s (Tool-Free) | <90s | <150s |
| Power | 380V/50Hz, 7.5kW | 380V/50Hz, 6.8kW | 380V/50Hz, 8.2kW |
Allergen Management Protocol
Preventive Measures:
Material-Specific Zones: Color-coded change parts
Airflow Containment: +5Pa Zone Pressure Differential
DNA Testing Port: PCR validation every 4hrs
Organic Integrity Assurance
| Component | Certified Solution |
|---|---|
| Auger System | USDA Organic-Compliant Lubricants |
| Sealing Tape | Certified Compostable Adhesive |
| Cleaning Agents | OMRI Listed Detergents |
**12" HMI with FoodOS?**
AI-Driven Features:
Contamination Sentinel:
| Risk | Action |
|---|---|
| Metal Detected | Instant Shutdown + Alarm |
| Allergen Trace | Line Lock & Auto-Purge |
Predictive Quality:
| Parameter | Precision |
|---|---|
| Moisture Content | ±0.05% (NIR Sensor) |
| Particle Size | Laser Diffraction (1-1000μm) |
1. Bag Auto-Loading → 2. UV-C Sterilization (99.999% Kill Rate) → 3. Precision Filling (±0.1%) → 4. Allergen Swab Test → 5. Multi-Mode Sealing → 6. X-Ray Inspection → 7. Palletizing
Cycle Time: 60 seconds/bag
Food Safety Excellence
? Zero-Cross-Contamination Design: | **Technology**| **Certification** | |-------------------------|--------------------------| | Zoned Pressurization| BRCGS AA+ Grade | | Magnetically Sealed Path | EHEDG EL Class I| | PCR Testing Port| ISO 16140 Validated| ? Particle Integrity Preservation: 1. Low-Shear Auger (15 RPM) 2. Air Cushion Flow Guidance 3. -40°C Dew Point Air Flush ? Industry-Leading Precision: - 0.05% Resolution Load Cells - Real-Time Density Compensation - ±0.1% Bag-to-Bag Consistency
? EHEDG EL Class I (Certificate #EH-2024-887) ? FDA 21 CFR 117 (FSMA Compliant) ? USDA Organic (NOP) ? SQF Level 3 with Quality Certification ? Halal & Kosher Certification
General Mills Facility Report:
"After implementing PF-7200A for wheat flour:
Output: 35 → 60 Bags/Hour (+71%)
Allergen Incidents: 3/year → 0
Moisture Control: ±0.08% (vs. ±0.5% industry)
Microbial Safety: ATP<2 RLU consistently"
