PalletDrum AutoFill PD-1000 SeriesFully Automated 200L Drum Filling SystemEnd-to-End Automation • 33 Drums/Hour • SIL-3 SafetyCore Automation WorkflowCycle Time: 2.5 min/drum (33 drums/hour)Technical
Fully Automated 200L Drum Filling System
End-to-End Automation ? 33 Drums/Hour ? SIL-3 Safety
Cycle Time: 2.5 min/drum (33 drums/hour)
| Parameter | PD-1100 (Standard) | PD-1200X (ATEX) | PD-1300H (High-Visc) |
|---|---|---|---|
| Capacity | 180-220L (±0.15%) | 180-220L (±0.2%) | 180-220L (±0.18%) |
| Throughput | 33 drums/hour | 30 drums/hour | 28 drums/hour |
| Accuracy | ±0.15% mass flow | ±0.2% | ±0.18% |
| Automation Level | Lights-Out Operation | Same + Gas Detection | Same + Viscosity Adapt |
| Robotic System | 6-Axis x2 (Fanuc CRX-10iA) | Same | 7-Axis Heavy Payload |
| Filling Technology | Dual Coriolis Meters | ATEX Diaphragm Pumps | Heated Screw Auger |
| Lid Handling | Vacuum Gripper + Vision | Magnetic Gripper | Dual Suction Cup |
| Power | 480V/60Hz, 28kW | 480V/60Hz, 30kW | 480V/60Hz, 35kW |
| Air Consumption | 450 L/min @ 0.7MPa | 420 L/min | 480 L/min |
| Pallet Compatibility | EUR/ISO/DIN Standard | Same + Custom | Same + Heavy-Duty |
| Footprint (L×W) | 12m × 8m | 13m × 8.5m | 12.5m × 8.2m |
| Operator Requirement | 0.5 FTE (Monitoring Only) | Same | Same |
| Sensor Type | Function | Precision |
|---|---|---|
| 3D Laser Scanner | Drum Position Detection | ±0.5mm |
| CCD Camera Array | Bung Hole Alignment | ±0.3° Angular Error |
| RFID Reader | Material Tracking | 100% Read Rate |
Synchronization Performance:
| Metric | Performance | Industry Standard |
|---|---|---|
| Nozzle Sync Error | <0.8% | 3-5% |
| Weight Variance | ±0.6% | ±2.5% |
| Flow Balance | 99.2% | 92-95% |
Central Control Hub Features:
Key Metrics Tracked:
OEE: 92.5% (Industry Avg: 68%)
Energy Consumption: 0.38 kWh/drum
Downtime: <1.2% (vs 8-12% conventional)
Triple-Redundant Protection:
| Layer | Technology | Certification |
|---|---|---|
| Physical | Light Curtains + Safety Scanner | ISO 13849 PLd |
| Process | SIL-3 Pressure/Temp Sensors | IEC 61511 |
| Environmental | ATEX Pressurized Cabinets | IECEx Zone 1/21 |
ROI Analysis (500 drums/day operation):
| Cost Factor | Manual Process | PD-1100 | Annual Savings |
|---|---|---|---|
| Labor | 3 Operators ($180k) | 0.5 FTE ($30k) | $150,000 |
| Product Waste | 3.5% ($420k) | 0.2% ($24k) | $396,000 |
| Lid/Drum Damage | 2.1% ($82k) | 0.05% ($2k) | $80,000 |
| Energy | $38,000 | $22,000 | $16,000 |
| Total Savings | - | - | $642,000/year |
| Payback Period: 14 months at $750,000 investment |
? ATEX 2014/34/EU (PD-1200X) ? ISO 10218-1 Robotic Safety ? SIL-3 IEC 61511 ? CE EN ISO 13849-1
*"After implementing PD-1100 for solvent filling:
Output: 400 → 792 drums/day (+98%)
Accuracy: ±2.1% → ±0.16%
Labor Injuries: 3/year → 0
VOC Exposure: 85 ppm → <1 ppm
ROI: 11 months"*
