Two Head Automatic Net Weight Liquid Filling Machine delivers the highest levels of automation and precision filling performance in a full-featured package.Automatic PLC-controlled filling, lid placem
Dual-Head Inline Net Weight Filling & Closing System with POP Cart Integration
Precision Gravimetric Filling ? 80 Units/Min ? ±0.05% Accuracy ? ATEX Zone 22 ? Retail-Ready Packaging
| Parameter | DF-9100 (Standard) | DF-9200X (ATEX) | DF-9300P (Pharma-Grade) |
|---|---|---|---|
| Capacity Range | Pint (473ml) to 20L Pails | Same | Same |
| Throughput | 80 Units/Min | 75 Units/Min | 70 Units/Min |
| Accuracy | ±0.05% Gravimetric | ±0.08% | ±0.03% |
| Container Types | Jars ? Bottles ? Pails ? POP Display Cartons<br>Material: Glass/Plastic/Metal<br>Lid: Screw Cap ? Press-On ? Tamper-Evident | Same | USP Containers |
| Filling Technology | Dual Coriolis Mass Flow Meters<br>Flow Rate: 100L/min/Head<br>Density Accuracy: ±0.01%<br>Head Sync Variance: <0.02% | ATEX Gear Pumps | Peristaltic Pumps (FDA) |
| POP Cart Integration | Auto-Loading Display System:<br>? 360° Rotating Cart<br>? Laser Coding Station<br>? RFID Inventory Tracking<br>? Max Load: 50kg | Same + ATEX Brushless | VHP-Sterilizable |
| Closing System | TorqueMaster? Servo Capper<br>Range: 0.5-20 N·m<br>Accuracy: ±0.5%<br>Cap Types: 15-80mm | Magnetic Clutch | Stepper Motor Control |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | Glass-Lined Path |
| Changeover Time | <45s (Tool-Free) | <60s | <30s |
| VOC Containment | TripleShield?:<br>1. -0.6bar Vacuum Hood<br>2. N? Blanketing (O?<0.3%)<br>3. Carbon Adsorption (99.97%) | + Explosion Venting | Ionic Filtration |
| Static Control | Ionized Air Curtain<br>10? ions/cm3 Output<br><0.1kV Surface Charge | NFPA 77 Compliance | ESD Grounding |
| Power | 480V/60Hz, 7.5kW | 24VDC Ex ia | 480V/60Hz, 6.8kW |
| Certifications | CE, ISO 9001 | ATEX Zone 22 | FDA 21 CFR 175.300 |
Performance Validation:
| Container | Capacity | Head 1 Accuracy | Head 2 Accuracy | Variance |
|---|---|---|---|---|
| Pint Jar | 473ml | ±0.04% | ±0.03% | 0.01% |
| 5L Pail | 5,000ml | ±0.05% | ±0.06% | 0.02% |
| 20L Pail | 20,000ml | ±0.07% | ±0.07% | 0.00% |
| Feature | Technology | Retail Advantage |
|---|---|---|
| Auto-Loading | Robotic Arm + Vision Guidance | Shelf-Ready in <10s |
| Laser Coding | Fiber Laser Marking | Permanent Batch/Date Codes |
| RFID Tagging | UHF RFID Inlay Printer | Real-Time Inventory Tracking |
| Tilt Prevention | Gyroscopic Stabilization | 0% Display Toppling |
1. Container Infeed → 2. Dual-Head Filling (±0.05%) → 3. Vacuum Drip Control → 4. Torque Capping (±0.5%) → 5. POP Cart Auto-Loading → 6. Laser Coding → 7. Weight Verification → 8. Palletizing
Cycle Time: 0.75 seconds/unit (Dual-Head)
Precision & Retail Integration
? Gravimetric Excellence: | **Component** | **Performance**| |----------------------|------------------------| | Load Cells| ASTM Class 0.02 | | Air Buoyancy Comp. | ±0.03% Error| | Temp Control| ±0.1°C Peltier System | ? Zero-Contamination Architecture: 1. Isolated Product Paths 2. <0.1ppm Carryover Guarantee 3. Color-Coded Quick-Change ? POP Cart Intelligence: - 360° Rotating Display - Anti-Theft Security Tags - Planogram Compliance Scanning
? ATEX 2014/34/EU Zone 22 ? FDA 21 CFR 175.300 ? GS1 Retail Ready Certification
Unilever Retail Packaging Hub:
"After implementing DF-9200X:
Output: 45 → 80 Units/Min (+78%)
Retail Setup Time: 15min → Automated
Shelf-Ready Compliance: 100%
ROI Period: 6 months"
APPLICABLE BARREL TYPE
