The fully automatic filling robots are mainly used in the fixed weight filling field of basic chemical, petrochemical, new energy, new materials, fine chemical, electronic chemicals, daily chemical, l
Fully Automatic 200kg Oil Drum Filling Line
Heavy-Duty Precision. Industry 4.0 Integration. Zero Spill Guarantee.
Parameter | OM-2100 (Standard) | OM-2200X (ATEX) | OM-2300H (High-Visc) |
|---|---|---|---|
Capacity | 150-220L (±0.15%) | 150-220L (±0.2%) | 150-220L (±0.18%) |
Throughput | 30 drums/hour | 26 drums/hour | 28 drums/hour |
Accuracy | ±0.15% mass flow | ±0.2% | ±0.18% gravimetric |
Viscosity Range | 10-200,000 cP | 50-150,000 cP | 500-800,000 cP |
Filling Technology | Coriolis meter + AI compensation | Ex-rated pumps | Heated screw (80°C±1°C) |
Material Contact | 316L SS + PTFE seals | Hastelloy C276 | Tungsten carbide coating |
Container Handling | Robotic arm (max 300kg) | ATEX-certified gripper | Vacuum drum lifter |
Oil Mist Control | >97% capture (RTO) | >98.5% (Carbon+Scrubber) | >96% (Condensation) |
Power | 480V/60Hz, 45kW | 24VDC Ex ia | 480V/60Hz, 55kW |
Nitrogen Consumption | 40 L/min | 50 L/min | 45 L/min |
Changeover Time | <5 min (tool-free) | <7 min | <6 min |
Safety Features:
Anti-Tip Clamps: Prevent drum wobble at 200kg load
Static Dissipation: <10? Ω grounding (NFPA 77)
Overflow Protection: Radar sensors ±1mm accuracy
Oil Type | Heating/Cooling | Fill Speed | Energy Efficiency |
|---|---|---|---|
Gear Oil (ISO VG 460) | 60°C jacket (±1°C) | 185 L/min | 0.15 kWh/drum |
Grease (NLGI #2) | Piston pulsation (20Hz) | 120 L/min | 0.22 kWh/drum |
Transformer Oil | -10°C cryo cooling | 210 L/min | 0.18 kWh/drum |
Validated by ExxonMobil Singapore:
*"After 6 months operating OM-2100:
Zero spills with 200kg drums
29.8 drums/hour sustained output
$2.1M/year saved in oil recovery
9 sec/drum faster than manual filling"*
15" Industrial HMI with PetroOS?
AI Modules:
Predictive Pump Maintenance:
Anomaly | Pre-Action |
|---|---|
Vibration >4.5mm/s | Auto RPM reduction + alert |
Temp deviation >2°C | Flow pause & heat adjustment |
Spill Prevention AI: 99.7% risk detection accuracy
? ATEX Category 1 (Zone 0/20) ? API 682 4th Edition ? ISO 80079-36/37 Explosive Atmospheres ? OSHA 1910.106 Flammable Liquids ? CE EN 415-9 Safety Standard
Module | Function | OM-2100 |
|---|---|---|
AGV Conveyance | Auto drum queuing (40 pallets) | Standard |
Robotic Unscrambler | Mixed drum size handling | +$48,000 |
VOC Condenser | >98% solvent recovery | +$62,000 |
Cryogenic Cooling | -30°C transformer oil fill | +$78,000 |
Cost Factor | Manual Line | OM-2100 | Annual Savings |
|---|---|---|---|
Labor | 4 operators | 0.5 supervisor | $316,000 |
Oil Loss | 3.2% | 0.05% | $185,000 (200kl/yr) |
VOC Fines | $45,000 | $0 | $45,000 |
Energy/Drum | 1.8 kWh | 0.17 kWh | $38,000 |
Total Savings | - | - | $584,000 |
ROI Period: 9 months (standard configuration)
Service | Basic | Platinum |
|---|---|---|
Spare Parts | 72h global dispatch | On-site inventory hub |
Uptime SLA | 98% with remote monitoring | 99.6% with AI predictive care |
Training | Virtual certification course | Onsite 5-day master program |
Calibration | Annual ISO/IEC 17025 | Real-time cloud adjustment |
APPLICABLE BARREL TYPE
