Shanghai Guangzhi’s Marmalade & Sauce Bottling Machine achieves ±0.5% filling accuracy at 40-60 jars/min. Features hot-fill capability, CIP sanitation & FDA-compliant design.
Shanghai Guangzhi Automation’s Automatic Bottling Machine delivers pharmaceutical-grade accuracy for viscous food products (marmalades, tomato sauces, chutneys) in 50g-250g glass/PET jars. Engineered with servo-piston filling (±0.5% accuracy), 85°C hot-fill capability, and hygienic CIP/SIP systems, it maximizes output while complying with FDA 21 CFR & EU 1935/2004 standards.
1. Viscosity-Adaptive Filling
Dual Servo-Pistons: Independently adjust stroke speed for products ranging from 1,000 cP (tomato sauce) to 50,000 cP (chunky marmalade).
Hot-Fill Ready: Heated manifolds (20–85°C) maintain product flow with ±1°C stability.
2. Zero-Contamination Design
FDA-Compliant Materials: 316L stainless steel contact surfaces + EPDM seals (EC1935/2004).
Anti-Drip Nozzles: Spring-loaded PTFE tips with <0.01g residual drip.
3. High-Speed Automation
Vision-Guided Jar Handling: Rotary indexing system positions jars (±0.2mm tolerance) at 60 jars/minute.
10" Recipe-Driven HMI: Stores 100+ formulations (e.g., viscosity/temp profiles for berry vs. citrus marmalade).
| Parameter | Specification |
|---|---|
| Filling Range | 50g–250g (±0.5%) |
| Max Viscosity | 50,000 cP |
| Speed | 40–60 jars/minute |
| Jar Compatibility | ?40–90mm × H50–120mm (Glass/PET) |
| Hot-Fill Temp | 20–85°C (±1°C) |
| Power | 220V/50Hz, 4.2kW |
| Air Consumption | 60 L/min @ 0.6MPa |
| CIP/SIP Cycle Time | <5 minutes |
| Footprint (L×W×H) | 2400×1300×1900mm |
| Product | Filling Solution | Sanitation Feature |
|---|---|---|
| Chunky Marmalade | Agitating hopper (anti-settling) | Brushless DC wiper seals |
| Tomato Sauce | Laminar flow nozzles (anti-aerating) | In-line metal detection |
| Seeds-Containing Jams | 3mm clearance piston heads | 360° spray ball CIP coverage |
GMP/ISO 22000 Design: Radiused corners (R≥6mm), sloped surfaces (≥3°)
Quick-Change Tooling: Tool-free format adjustment in <3 mins
Traceability: Laser-etched batch codes + OPC UA data export to ERP
Certifications: CE, FDA 21 CFR 177.2600, EHEDG EL Class I
Case Study: Italian Condiment Producer
Challenge: 6% overfill in 150g marmalade jars + product temperature instability
Solution: Integrated hot-fill filler with servo-piston control
Results:
0.6% material savings ($182K/yr)
Zero microbial recalls in 24 months
54 jars/min sustained output
| Critical Option | Technical Benefit |
|---|---|
| Aseptic Nitrogen Flush | O? <0.1% in headspace (shelf-life +30%) |
| Weight Checker Conveyor | 100% fill weight verification (±0.1g) |
| Allergen Clean-Out Kit | <10 ppm cross-contact (nut-free lines) |
| AR Guidance Maintenance | 40% faster technician response |
Service Commitment:
Sanitary spare kits (seals/nozzles) global dispatch ≤24h
Remote diagnostics with live OEE dashboards
