AquaFill Pro AF-2000 SeriesSemi-Automatic Desktop Emulsion Paint Filling SystemPrecision Gravimetric Filling • 30 Bottles/Hr • ±0.1% Accuracy • Foam-Free Technology • EHEDG/FDA CertifiedCore Technical
Semi-Automatic Desktop Emulsion Paint Filling System
Precision Gravimetric Filling ? 30 Bottles/Hr ? ±0.1% Accuracy ? Foam-Free Technology ? EHEDG/FDA Certified
| Parameter | AF-2010 (Standard) | AF-2020P (Pharma-Grade) | AF-2030H (High-Viscosity) |
|---|---|---|---|
| Capacity | 10L (±0.1%) | 10L (±0.08%) | 10L (±0.15%) |
| Throughput | 30 Bottles/Hr | 28 Bottles/Hr | 25 Bottles/Hr |
| Accuracy | ±0.1% Gravimetric | ±0.08% | ±0.15% |
| Viscosity Range | 50-50,000 cP | 50-30,000 cP | 500-500,000 cP |
| Foam Control | TripleDefoam? System:<br>1. Vacuum Submerged Filling (-0.6bar)<br>2. Ultrasonic Agitation (40kHz)<br>3. Coanda Adhesion Nozzle | Same + N? Blanketing | Shear-Thinning Nozzle |
| Filling Technology | Servo Piston + Coriolis Meter | Peristaltic Pump (FDA) | Gear Pump with Pre-Heating |
| Material Contact | 316L EP (Ra<0.4μm) | Glass-Lined Path | Tungsten Carbide (2,200 Hv) |
| Container Compatibility | HDPE/PP Bottles ? Jerrycans<br>Lid: Screw Cap ? Press Seal ? Tri-Clamp | USP Containers | UN-Certified Containers |
| Cleanability | CIP 12-min Cycle<br>ATP<3 RLU Validation | SIP/CIP 10-min Cycle | Solvent Purge System |
| Footprint | 600×450×500mm | Same | Same |
| Power | 220V/50Hz, 850W | 220V/50Hz, 780W | 220V/50Hz, 1.2kW |
| Certifications | CE, EHEDG EL Class I | FDA 21 CFR 175.300 | ISO 9001:2015 |
Performance Validation:
| Emulsion Type | Viscosity | Foam Height | Industry Standard |
|---|---|---|---|
| Acrylic Latex | 1,200 cP | 0mm | 15-25mm |
| PVA Primer | 800 cP | 0mm | 10-20mm |
| Epoxy Waterborne | 20,000 cP | 0mm | 20-35mm |
| Component | Technology | Performance |
|---|---|---|
| In-line Spectrophotometer | CIELab ΔE Measurement | ΔE<0.3 |
| Real-Time Viscosity Control | Ultrasonic Rheometer | ±1% Brookfield |
| Batch Matching | AI-Formula Adjustment | ±0.5% Color Variance |
1. Manual Bottle Loading → 2. Auto-Nozzle Alignment (±0.5mm) → 3. Nitrogen Purging (O?<0.3%) → 4. Vacuum Filling (±0.1%) → 5. Ultrasonic Defoaming → 6. Drip-Free Retract → 7. Torque Capping (5-20 N·m) → 8. Weight Verification
Cycle Time: 120 seconds/bottle
Precision & Efficiency
? Zero-Foam Guarantee: | **Technology**| **Performance**| |-------------------------|------------------------| | Vacuum Submersion| -0.6bar ±0.05bar | | Coanda Nozzle| 0 Bubble Formation| | Ultrasonic Defoamer| 40kHz Frequency | ? Color-Perfect Architecture: 1. Real-Time Spectrophotometer 2. Auto-Density Compensation 3. Batch-to-Batch ΔE<0.3 ? Industrial-Grade Reliability: - Tungsten Carbide Components (2,200 Hv) - IP66 Washdown Protection - 100,000-Hour MTBF
? EHEDG EL Class I (Certificate #EH-2024-771) ? FDA 21 CFR 175.300 ? ISO 9001:2015
PPG Architectural Coatings Facility:
"After implementing AF-2010:
Output: 18 → 30 Bottles/Hr (+67%)
Foam Waste: 8L/day → 0.1L/day
Color Variance: ΔE>0.8 → ΔE<0.2
ROI Period: 4 months"
