EmulFill EF-5000 SeriesAutomatic Multi-Barrel Explosion-Proof Filling Line for 10-30L EmulsionsATEX Zone 1 Certified • 45 Barrels/Hr • ±0.15% Accuracy • Triple Containment • Industry 4.0 IntegrationCo
Automatic Multi-Barrel Explosion-Proof Filling Line for 10-30L Emulsions
ATEX Zone 1 Certified ? 45 Barrels/Hr ? ±0.15% Accuracy ? Triple Containment ? Industry 4.0 Integration
| Parameter | EF-5100 (Standard) | EF-5200X (ATEX) | EF-5300P (Pharma-Grade) |
|---|---|---|---|
| Capacity Range | 10-30L (±0.15%) | 10-30L (±0.2%) | 10-30L (±0.1%) |
| Throughput | 45 Barrels/Hr | 40 Barrels/Hr | 38 Barrels/Hr |
| Barrel Heads | 6 Simultaneous Fill Heads | Same + ATEX Brushless | 4 Heads (cGMP Design) |
| Accuracy | ±0.15% Gravimetric | ±0.2% | ±0.1% |
| Viscosity Range | 100-1,000,000 cP | 500-800,000 cP | 50-2,000,000 cP |
| Explosion Protection | ATEX Zone 1/21 | IECEx Zone 0 | ATEX + cGMP |
| Filling Technology | Gear Pump + Coriolis Meter<br>Per Head: 60L/min<br>Head-to-Head Variance: <0.1% | ATEX Diaphragm Pump | Peristaltic Pump (FDA) |
| Containment System | TripleShield?:<br>1. Nitrogen Inerting (O?<0.3%)<br>2. -0.8bar Vacuum Hood<br>3. HEPA H14 Filtration | + Explosion Venting | VHP Sterilization |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | Glass-Lined Path |
| Line Integration | OPC UA/MQTT/PROFINET<br>? Auto-Recipe Change<br>? Predictive Maintenance<br>? <50ms Response | Same + SIL-3 | 21 CFR Part 11 |
| Container Types | Steel/Plastic Barrels ? Jerricans ? Composite Drums<br>Lid: Tri-Clamp ? DIN ? Camlock | UN-Certified | Aseptic RTP |
| Changeover Time | <120s (Auto-Tooling) | <150s | <90s |
| Power | 480V/60Hz, 22kW | 24VDC Ex ia | 480V/60Hz, 18kW |
| Certifications | CE, ISO 9001 | ATEX/IECEx Zone 0 | FDA 21 CFR 175.300 |
Performance Validation:
| Emulsion Type | Viscosity | Fill Consistency | Industry Standard |
|---|---|---|---|
| Acrylic Paint | 80,000 cP | ±0.12% | ±0.8% |
| Epoxy Resin | 350,000 cP | ±0.18% | ±1.2% |
| Silicone Emulsion | 150,000 cP | ±0.09% | ±0.9% |
| Layer | Technology | Certification |
|---|---|---|
| Primary Barrier | Double Mechanical Seal | API 682 Plan 53B |
| Secondary Defense | -0.8bar Vacuum Hood | EN 13445 PED |
| Tertiary Capture | Activated Carbon Adsorption | EPA Method 25 |
Smart Factory Integration:
IIoT Features:
Predictive Analytics:
| Parameter | Action |
|---|---|
| Viscosity Shift >10% | Flow Profile Adjustment |
| Seal Wear >80% | Maintenance Alert |
OEE Optimization:
| Metric | Control |
|---|---|
| Energy Consumption | Adaptive Speed Control |
| VOC Emission | Carbon Saturation Alert |
ATEX Zone 0 Compliance:
| Component | Protection Method | Standard |
|---|---|---|
| Electrical | Intrinsic Safety (Ex ia) | IEC 60079-11 |
| Mechanical | Nitrogen Inerting (O?<0.5%) | EN 60079-2 |
| Static Control | Ionized Air Curtain (10? ions/cm3) | NFPA 77 |
Material Science:
Hazardous Environment Compatibility:
| Part | Material | Temp Class |
|---|---|---|
| Pump Housing | Hastelloy C276 | T4 (135°C) |
| Seals | Kalrez?6375 | T3 (200°C) |
| Sensors | Epoxy-Encapsulated | T6 (85°C) |
1. AGV Pallet Delivery → 2. Robotic Lid Removal → 3. Nitrogen Purging (O?<0.3%) → 4. 6-Head Filling (±0.15%) → 5. Vacuum Nozzle Retract → 6. Torque-Sealing (50-150 N·m) → 7. Helium Leak Test → 8. VOC Recovery → 9. Automated Palletizing
Cycle Time: 80 seconds/pallet (6 barrels)
? ATEX 2014/34/EU Zone 0/1 ? IECEx IEC 60079-0/11/31 ? FDA 21 CFR 175.300 ? ISO 9001:2015
Global Chemical Manufacturer:
"After implementing EF-5200X:
Output: 24 → 45 Barrels/Hr (+88%)
VOC Emissions: ↓99.2% (Carbon Adsorption)
Accuracy: ±0.7% → ±0.12%
ROI Period: 9 months"
