    200kg Chemical Raw Materials Fully Automatic Filling Machine



                            2025-05-12 16:19:36
                            glzon










    Fully Automatic Filling Machine
    Basic Info.
    Type
    Weighing-type Filling Machine
    Automatic Grade
    Fully Automatic
    Material Type
    Liquid
    Filling Valve Head
    Multi-Head
    Feed Cylinder Structure
    Multi-Room Feeding
    Dosing Device
    Capacity Cup
    Filling Principle
    Pressure
    Packaging Container Lifting Structure
    Pneumatic Lifting
    Structure
    Linear
    Packaging
    Barrel
    Packaging Material
    Wood
    Barrel Form
    Pail, Can, Bottle, etc.
    Application
    Food, Beverages, Daily Necessities, Chemicals
    Suitable Material
    Coatings, Inks, Paints, Asphalt, Glue, Lubricants
    Applicable Industries
    Hotels, Manufacturing Plants, Food and Beverage Pl
    Transport Package
    Wooden Cases
    Specification
    1225*660*1180
    Trademark
    GLZON
    Origin
    Shanghai, China
    Product Description
    Automatic Meter Filling Line for Filling 200L Drum Liquid/Glacial Acetic Acid/Epoxy Resin
    200kg Chemical Raw Materials Fully Automatic Filling Machine
    Product Description

    Introduction
    Liquid filling line is a highly automated packaging equipment, whose main function is to automatically fill liquid materials into predetermined weights. The liquid filling machine can effectively prevent material overflow during the filling process, effectively prevent material pollution to the environment, and provide effective labor protection for operators. Its system works stably and reliably, with simple operation and precise filling. The filling line mainly consists of a filling gun device, PLC system control part, weighing system, filling rack, conveying equipment, etc.
    200kg Chemical Raw Materials Fully Automatic Filling Machine
    200kg Chemical Raw Materials Fully Automatic Filling Machine

    Features
    1.For the filling of square barrels and drums below 100kg, the system adopts programmable PLC control, with full Chinese guid- ance and easy operation;
    2.The filling head extends into the barrel mouth and automatical- ly exits when filling is completed. If the filling head is not aligned with the barrel mouth, it will automatically return;
    3.The filling gun is made with integral technology to prevent dripping and splashing; the quick-release connector is easy to disassemble and clean;
    4.The system target value can be set freely, and the height of the filling gun is adjustable, suitable for rapid filling of packaging barrels of various specifications;
    5.Equipped with a large and small ball width group and a double-stage filling gun, the four-stage filling design of large, medium, small and trace quantities makes filling more accurate;
    6.Filling is prohibited without a bucket on the weighing platform, and differential pressure zero-time bucket collision protection is provided;
    7.Net weight/gross weight (automatic tare for each barrel) Two filling methods are automatically selected;
    8.One-click operation, easy to use; multiple windows display filling volume, number of barrels, cumulative volume and other information;
    9.There is a signal indicator light for real-time display, and an automatic alarm if the deviation is exceeded;
    10.It has good stability,reduces losses,saves costs,improves operating efficiency and reduces manual operation pressure.
    Product Parameters
    200kg Chemical Raw Materials Fully Automatic Filling Machine
    Product Parameters
    Model
    GZM-200AUTO-2PT
    Filling range100-200kg
    PowerAC220V±10%50hz
    Air source0.5mpa
    Applicable materialsCoatings, inks, paints, asphalt, glue, lubricants, petrochemicals, fine chemicals and other liquids
    Filling accuracy0.02%
    Speed(can/min)1-2 barrels (1000L)
    Filling station2
    Materialsus304/316
    Installation Instructions
    Main structure and working principle

    1.Computer quantitative filling machine has feeding system, weighing system frame pneumatic control control system without power raceway and so on.

    2.Feeding mode: the requirement of continuous and stable feeding (feeding pump pressurized feeding) feeding mechanism by solenoid valve through the cylinder to perform fast and slow feeding.

    3.Filling method: ordinary conventional filling and lifting and diving filling (according to the needs of the order to choose).

    4.The weighing platform is equipped with unpowered roller and frame support and filling system pneumatic control system: control fast and slow feeding valve in the process of using the weighing platform is not allowed to be subjected to additional external forces.
    200kg Chemical Raw Materials Fully Automatic Filling Machine200kg Chemical Raw Materials Fully Automatic Filling Machine
    Working process:

    @The operator places the drum on the filler

    @The operator aligns the nozzle to the drum

    @The operator presses the button of " filling orientation" at first, then presses the button of "start filling", filling nozzles lowing down,start filling automatically

    @When it comes to the weight set, automatically stops filling and nozzle out of the drum

    @The operator push out the drum

    Company Profile

    200kg Chemical Raw Materials Fully Automatic Filling Machine
    Shanghai Guangzhi Automation Equipment Co., Ltd. is a professional production and sales of packaging machine, filling machine factory, our company is located in Shanghai Songjiang Industrial Zone, covers an area of 5000 square meters, adjacent to the G60 science and innovation corridor, has rich industry experience, excellent human resources, excellent technical ability.
    Since its establishment in 2010, our company has been committed to R & D, design, production to make customers more satisfied with the products, to provide quality after-sales service system, in the continuous efforts of all staff, our equipment is not only in the country c    hemical, construction and other industries have made achievements, but also exported to 49 countries around the world, and set up agents in South America, East Asia, Africa, more with the world.
